• Depending on the teach-in variant used (see Subsection 6.3),
the brightness criterion (e.g. only switch when dark) may also be
transferred.

9 Restore factory settings

• Press and hold the teach-in button on the wireless motion detector
for at least five seconds. The device LED starts to slowly flash red.
• Press and hold the teach-in button for at least another five seconds.
The LED will now start to flash red faster.
• Release the teach-in button to complete the process. The LED
briefly lights up red, green and orange in sequence to confirm that
the reset has been successful.
Possible error messages:
(This error can only occur if you have a central control unit to which you
have taught-in the device.)
If the LED does not start to flash when the button has been held down
for five seconds, but lights up continuously instead, the device cannot be
reset.
In this case, coding is activated using a system security key that differs
from the one supplied with the product.
To reset the sensor, you will have to use the configuration software for
resetting the central control unit. The procedure to follow is described in
the manual for the central control unit software (available for download in
the „Downloads" area of the website www.homematic.com).

10 Maintenance and cleaning

This product does not require you to carry out any maintenance other than
replacing the batteries when necessary. Enlist the help of an expert to
carry out any maintenance or repairs.
Clean the product using a soft, lint-free cloth that is clean and dry. You
may dampen the cloth a little with lukewarm water in order to remove more
stubborn marks. Do not use any detergents containing solvents, as they
could corrode the plastic housing and label.
Protect the product from the effects of damp, dust and direct solar radiati-
on.
34

11 Technical data

PIR sensor characteristics:
- Main lens
· Range/sensing angle: 12 m approx./90° approx.
- Creep zone protection
· Range/sensing angle: 4 m max./43° approx.
Swivel range: ±45°
Radio frequency: 868.3 MHz
Typ. open air range: 300 m
Power supply: 3 x LR6/AA/Mignon
Battery life: ≥ 1 year
Degree of protection: IP20
Dimensions (ø x H): 55 x 132 mm
Subject to technical changes.
Note on disposal
Do not dispose of the device as part of household waste!
Electronic devices are to be disposed of in accordance with the
guidelines concerning electrical and electronic devices via the
local collection point for old electronic devices.
The CE sign is a free trade sign addressed exclusively to
the authorities and does not include any warranty of any
properties.
