4.

OPERATION

4.1 ADJUSTMENT OF THE TWIST-IN EYE CUPS
Use without eyeglasses:
Use with eyeglasses:
4.2 ADJUSTMENT OF INTERPUPILLARY DISTANCE
To see a single round image, turn the two hal-
ves of the binoculars until no irritating shadows
can be seen.
14
CL COMPANION POLARIS / EN CL COMPANION POLARIS / DE
Turn both eye cups
(counter-clockwise) until
they stop.
Turn both eye cups clock-
wise until they stop.
4.3 ADJUSTMENT OF FOCUSING
In the infinity position the little nose of the focu-
sing wheel is at the top.
4.4 DIOPTRIC COMPENSATION
To achieve optimal image quality, the possibly
varying visual acuity between the left and right
eye must be corrected.
Use with equal acuity of both eyes:
Use with varying acuity of both eyes:
1. Look through the left ocular with your left eye
and turn the focusing wheel to focus sharply
on a selected object.
2. Now, using your right eye, look at the same
object through the right eyepiece and use
CL COMPANION POLARIS / EN CL COMPANION POLARIS / DE
It is possible to bring
every subject into focus
from the shortest adju-
stment distance (see
technical data sheet) to
infinity by turning the
focusing wheel.
The dioptric compensa-
tion is set to "zero".
15
