Technical Data; Before Using - EINHELL LEF 30 Originalbetriebsanleitung

GB

4. Technical data

Power supply:
Max. rated current consumption:
Max. compressor starting current:
Max. power consumption:
Sound pressure level:
Dehumidifying capacity:
1.25 l/h (at a room temperature of 30°C and air
0.62 l/h (at a room temperature of 27°C and air
Operating range for humidity
Operating range for temperature:
Max. air flow volume:
Volume of condensate container:
Coolant:
Refrigerant group:
Coolant quantity:
Appliance dimensions:
Appliance weight:

5. Before using

The unit switches off automatically once the set
humidity is attained and switches on once the set
humidity is exceeded.
The unit switches off automatically as soon as the
condensate collector is full.
Constant condensate drainage can be set.
Operating principle
The dehumidifier controls the relative humidity of the
inlet air. The humid air condenses on the cooler
elements and is transferred to the water tank. The
dry air is heated a little on the condenser and
returned to the room. A refrigerant compressor is
needed for operation.
Notes:
The room temperature should lie in the range
from 8 to 35°C. The dehumidifier will not work
effectively outside this range.
To achieve an optimum circulation of air it is
recommended that the appliance be set up in the
middle of the room as far as possible.
Avoid open windows and doors and entering and
leaving the room frequently, etc.
The appliance must never be used in excessively
dusty rooms or rooms with excessive amounts of
10
220-240 V ~ 50 Hz
2.7 A
3.1 A
560 W
≤ 50 dB(A)
humidity of 80%)
humidity of 60%)
40-80%
8-35°C
210 m 3
7 liters
R134a
L1
230 g
645 x 342 x 320 mm
17,3 kg
chlorine.
The dehumidifying performance of the appliance
is dependent on the characteristics of the room,
the room temperature and the relative humidity.
If the condensate container is not fitted correctly,
the appliance will not work.
To prevent high starting currents the appliance is
equipped with a restart inhibit which only restarts
the compressor after a delay of 3 minutes.
6. Operation
Switching the appliance ON and OFF (Fig. 3)
Check that the voltage on the rating plate is the same
as your supply voltage. Insert the plug into the socket
230 V ~ 50 Hz
If the rotary switch (13) is on "MAX" the air will
constantly be dehumidified.
By turning the switch in a clockwise direction, a
higher dehumidification level is set.
To switch the device off, turn the switch to "min".
Use the switch (14) to set the ventilator speed to
"high" or "low".
Note: If the position of the air humidity regulator (13)
is halfway between the two, the ON/OFF level air
humidity is set to approx. 55-65 %
Emptying the water tank
The device switches off automatically whenever the
condensed water tank is full, and the "Condensed
water tank full" LED lights up.
Remove the condensate collector by pulling it out
carefully forward out of the housing and then empty
it.
After emptying the tank, return it to its proper place.
Note:
If the tank is not inserted correctly the "Condensed
water tank full" LED will continue to shine.
Continuous operation
For continuous operation or longer operation time,
please note the following:
1. Switch the dehumidifier OFF and pull the power
plug.
2. Remove the condensate collector.
3. Remove the cover for the hose grommet (Fig. 2 /
Item 8) with a tool (e.g. carpet knife).
4. Insert a hose with 14mm internal diameter
through the uncovered hose grommet.
5. Attach a hose clamp to the hose.
6. Attach the hose to the water mains and secure it
with the hose clamp.
