indexa DF400SET Bedienungsanleitung Seite 44

[47] System settings (see fig. H)
[62] Date and time
[63] Menu language
[64] Display settings
[65] Display in passive mode
If the menu is closed the display changes after two minutes without a mouse click into passive mode. Here the desired display can be
set: Quad / Smart-Quad / sequence with 10 second interval / sequence with 5 second interval. In sequence all activated cameras will
be displayed in turn.
Factory setting: Smart-Quad
Note:
[66] Energy saving mode
Select here if the display should switched off after 5 or 10 minutes with no mouse click, or if it should always be on. The display will
automatically switch on by mouse click, by motion detection or by the start of scheduled recording.
Factory setting: always on
[46] Storage settings (see fig. I)
[67] Select storage for recording / activate ring mode
For the connected storage the total and the free storage capacity will be shown. Click on the storage onto which should be recorded (left
symbol for USB and right symbol for microSD card). Click again to select or deselect ring storage [71].
Note:
[68] Format storage device
Select the storage device for formatting.
Note:
[69] Network settings / change password
Do not change the DHCP setting (this enables the automatic connection of the smart recorder to the network)
• To change the password, click on „DCHP", enter the new password and confirm by clicking „OK".
[70] System information / Firmware update
Following data is displayed: Firmware version / internet setting / information of paired cameras / DID (device identification number of
44 - GB
Set using the arrows (YYYY - year / MM - month / DD – date / HH - hour / MM minute).
Select from English, French, Spanish, German, Japanese, etc.
Reception symbol
Click on the symbol until it lights red (symbol activated) or it does not light (symol deactivated).
Factory setting: activated
Note: The symbol does not appear on recordings
Date and time stamp
Click on the symbol until it lights red (symbol activated) or it does not light (symbol deactivated).
Factory setting: activated
Note: If the stamp is deactivated at the time of a recording, date and time will not be shown on the recording.
Also in sequence mode automatic and manual recordings can be made.
• Select only a storage which is connected to the smart recorder. If a storage is selected that is not available, no recording will be
made. This problem will not be indicated on the display for automatic recording, only by manual recording will this problem be
indicated on the display.
• If the ring storage function is not selected, and the storage is full, no more recordings can be made. In this case insert a new
storage, delete the recordings by „Storage Format " [68] or activate the ring function.
• The storage medium is shown on the live display by the symbol YYY for microSD card and by YYY for USB device.
After formatting all data will be deleted
the smart recorder) / password.
The QR code on the display also contains the DID
