Operating instructions
GB
1. Introduction
Read through these operating instructions fully and carefully. The operating
instructions belong to this product and contain important points concerning
bringing the appliance into service and its operation. Always pay attention to all
safety instructions. Should you have any questions or be unsure about operating
the appliance ask a specialist. Keep these instructions in a safe place and should
the need arise pass them on to a third party.

2. Proper use

The DF400 Set consists of the smart recorder DF400R and two cameras DF400K
each with a mains adapter.
It is to be used for the surveillance of rooms, entrance hallways, driveways etc.
through video pictures and sound. The video and audio transmission is wireless
using a frequency of 2.4GHz.
The power is supplied through the supplied mains adapters connected to a
230VAC, 50Hz mains supply.
If there is sufficient light a colour picture will be transmitted. At low ambient light
levels the integrated Infrared LEDs are automatically switched on. In this case the
immediate area (max. 14 m) will be illuminated and the video picture switches to
black and white mode for improved light sensitivity. The picture quality is
optimised for day and night operation by an internal mechanical filter change. If
the surveillance is specifically required in a dark environment, then additional
lighting should be installed.
Images from up to four wireless cameras DF400K can be received by the smart
recorder DF400R. Additional cameras DF400K are available as accessories.
The images can ve viewed on a monitor (not included) connected with HDMI
cable. The settings can be made in the on-screen menu using a mouse.
camera channels can be manually selected or automatically displayed in
sequence if the scan mode is selected.
on a split screen (various split formats possible).
The wireless transmission is digital and on constantly changing frequencies
(frequency hopping) which are synchronised between the camera and the smart
recorder. Only the smart recorder which has been "paired" with the camera can
receivethesynchronisedsignals.Thissecurityfeaturepreventsaccessofthecamera
signalbythirdparties.
The cameras are weatherproof (Protection class IP66) and can be used not only
indoors but also for mounting outside. Wherever possible they should be protected
from direct rainfall. The smart recorder and the mains adapters are for indoor use
only and must be protected from moisture.
VideoandsoundcanberecordedontomicroSDHCcard,USBstickorexternalhard
drivewithmainsadapter(noneincluded).
using a schedule, or automatically through a motion detection software.
possible to store the recordings in a ring format so that the oldest recordings will
be automatically overwrittenwhen the card is full.
a
calend r is used for the event log and for scheduled recordings.
be viewed directly on a connected monitor, using a PC or through an App on a
smartphoneortablet.
Motion within a range of up to 14 m can be detected by a PIR motion sensor in
the camera. In order to better detect motion at a higher ambient temperature or
directly towards the camera, a software based motion detection can be switched
38 - GB
They can also be viewed at the same time
Therecordingcanbestartedmanually,
The built-in real time clock and
The recordings can
on additionally. If the smart recorder DF400R is connected with network cable
to the internet via a WiFi router, the set can be controlled via app per
smartphone or tablet-PC (free Apps for iPhone and Android are available, not
suitable for Windows and Blackberry smartphones; DSL speed of minimum 512
Kbps and at least 3 G receiving quality necessary).
an IP address and access via browser is not possible.
a notification is possible.
The set is for use in private households. A video surveillance system does not
replace your duty of care or supervision. Observe the regulations concerning video
surveillance in commercial and public areas.
Any other use or modification of the device is not authorised. No liability will be
accepted for consequential damages or for damages caused by improper use or
incorrect operation. No liability will be accepted for consequential damages
caused by any function or by malfunction. Unless any liability is specifically
required by law, claims for damages, in particular those for personal injury or
property damage caused by non-functioning or malfunctioning of the machine,
are excluded. This appliance is not intended to be used by people (including
children) with restricted physical, sensory or mental capacities, or a lack of
experience and/or knowledge, unless they are supervised by, or receive
instructions how to use the appliance from a person responsible for their safety.

3. Package contents

!
2x Camera with connection cable to mains adapter
!
2x Antenna for camera
!
2x
Camera bracket with screws and plugs
!
2x Mains adapter for camera
!
Smart recorder
!
Antenna for smart recorder
!
Mains adapter for smart recorder
The
!
USB mouse
!
HDMI cable
!
Network cable
!
User manual

4. Features and Equipment

Smart recorder DF400R (s. fig. A)
1 Antenna
2 On/off switch
Connection-LED
3
4 Slot for microSD card
5 Antenna connection
6 Reset button
It is
7 Mains adapter connection
8 Power-LED
9 Connection for WiFi router
10 2x USB connection (for mouse
and optional external memory)
11 HDMI connection (video and
audio)
15 Mouse
22 Mains adapter
It is not necessary to set up
In case of motion detection
(s. fig. A)
28 HDMI cable
32 Network cable
Camera DF400K (s. fig. A)
12 Motion sensor
13 Power LED
14 Infrared LEDs
16 Daylight sensor
17 Lens
18 Connection-LED
19 Antenna
20 Bracket
21 Wing screw
23 Antenna connection
24 Fixing hole for bracket
