Technical Specifications - Siemens SIMATIC NET CP 5511 Installationsanleitung

3

Technical Specifications

Transmission rate
Electrical Values
Operating voltage
)
Rated voltage (limit values
Current consumption at rated
voltage
MTBF
Connector to
PROFIBUS
Type of transmission
Noise emission
FCC class
CP 5511 Installation Instructions/Product Information
A5E00102069–04
Technical Specifications
9.6 Kbps to 12 Mbps
Safety extra-low voltage (SELV)
complying with EN 60950
5 VDC (4.75 to 5.25 V)
typ. 270 mA, max. 360 mA
33 years
9-pin sub D female connector with
screw locking mechanism.
RS 485 floating within the SELV li-
mits
B complying with VDE 0875,
T.11=EN 55011 = CISPR 11
B
23
