3 Pin-Belegung

3-pol. XLR-Stecker:
Pin 1= Ground
Pin 2 = 0-10 V+ DC
Pin 3 = 12 V+ DC input

4 Funkschalter

[1] Taste 1
[2] Taste 2
[3] Taste 3
[4] Taste 4
[5] Blaue LED
[6] Rote LED
[7] Kreuzschlitzschrauben
[1]
[2]
[3]
[4]

3 Pin assignment

3-pin XLR-connector:
Pin 1= Ground
Pin 2 = 0-10 V+ DC
Pin 3 = 12 V+ DC input
3 Radio transmitter
[1] Button 1
[2] Button 2
[3] Button 3
[4] Button 4
[5] Blue LED
[6] Red LED
[7] Crosshead screws
[5]
[6]
5
[7]
