Code
Beschreibung
1
Bare main frame
4
Seat frame
5
Rear leg
7
Heel Support bracket
8
Ankle strap with buckle
9
Front leg frame part only.
11
Bearing housing
12
Bearing NSK 6005zz
13
Main pulley shaft
14
Belt pulley
15
Large pk transmission pulley
16
C clip stw-25
17
Key way 7x7x32
18
Washer steel 40x25.5x2
19
INA clutch bearing 25mmx30
21
Pulley decal
22
Aluminum tank back
23
Bearing NSK6205ZZ
24
Tank shaft seal housing.
25
Seal nbr 37x8x30
26
Small pk transmission pulley
27
Stainless adjuster shaft
28
Stainless backing plate
30
Blue poly backing ring.
31
Grub screw M8x8
32
Adjuster O Ring 12x9x1.5
33
Stainless washer 10x4.2x1
34
Stainless nut M4
35
Stainless bolt M4
36
Back ring s/s screw m3x20
37
Resistance handle decal
38
Tank plug with breather
39
Tank plug O Ring 42x26x3
40
Tank bolt 12x140mm
42
Nut M12
43
Washer 24x13x2
44
Tank black outer cover ring.
45
Polycarbonate tank.
46
Tank large seal.
Code
Beschreibung
47
Impeller blade
52
Grub screw mM4x6
57
Rare earth magnet 4mm
59
Tank level decal.
62
tank screw M3x10
63
Tank bolt M12x40
66
100mm end cap
67
Rubber cover.
68
Large side cover.
69
75x50mm cap
70
M4x10 screw
72
Small side cover
73
Left aluminum seat rail.
74
Right aluminum seat rail
75
Bearing NBN6301zz
76
PU seat wheel.
77
12mm shaft 12*149
78
C clip stw-12
79
Seat
80
M6x20 seat bolt
81
Seat washer 13x6x1.2
82
Washer 21x11x2
83
M10x20 bolt
84
Bungee pulley
85
Bearing NBN-6201ZZ
86
C Clip RTW-32
87
Spacer 16x12x12.5
88
Bolt M12x50
91
Bungee shock cord
94
Bungee hook end.
96
M10x70 seat rail bolt
97
M10 dome head nut
98
M6 nut.
100
Washer 13x6x1.5
101
Rubber bumper
102
Aluminum rail large decal
103
Transport wheel.
104
Spacer 16x10x12
105
Shaft
Code
Beschreibung
106
Rail small decal
107
Rail spacer
109
PK belt 7 rib 926mm
111
Belt guard aluminum.
112
Computer mount arm.
114
Bushing
115
M10x80 bolt
116
M10x60 bolt
117
Sensor wiring.
119
Stainless handle catch. (1 only)
120
M6x10 bolt
121
3m foot plate (1 only)
122
Frame caution decal
123
Handle centre rubber cover
124
Rower handle.
125
Handle rubber cover ring (1 only)
126
Hand grip 28x150 (1 only)
127
Rowing belt with end insert.
128
Foam handle insert
129
How to use decal
135
Rubber rear leg insert (1 only)
136
Impeller centre shaft
137
Belt pulley spacer
138
Shaft washer
139
Spring washer
140
10x47.5mm rear leg bolt (takes 6mm insert bolt)
141
10mm nylock nut
144
Rower handle end inserts.
145
Bearing spacer
146
NSK 6006 ball bearing
156
Sensor bracket
157
Sensor round, mounts in fdr-3-68
158
Magnet Ring
167
Tank Adjuster Bolt.
168
3mm washer
Wiring from computer to lower frame for heart rate
169
optional connection.
184
Tank level resistance handle
193
PU Yellow resistance handle cover
903
Computer. no h/receiver.
