Control Settings

THERMOSTAT
Adjust the temperature of the sauna by simply turning the operating knob.
Thermostat support automatically the choosen temperature.
In case the heater overheats, the safety sensor will automatically stop the
heater even if the timer is on. Find out for what reason the heater
overheated. The reason for this could be too tightly or too loosely placed
sauna stones, heater´s location or inappropriate ventilation. Exposure of the
sensor to the glowing heating element may cause sensor to overheat. Find
out the reason for overheating and fix the problem before resetting the
safety sensor. The reset button is located below the temperature knob. Refer
to Fig. 4.
TIMER
The timer has 1-8 (white) hours presetting time and 1-4 (pink) hours
operating time.
To start the heater at once, turn the knob to anywhere between 1-4 on the
operating time scale. The heater will start and remain on for the time
selected.
To preset the timer, simply turn the knob to anywhere between 1-8. When
the specific number of hours is reached, the heater will start running and
stay on for up to 4 hours if you don´t turn it off earlier.
Anschlußplan
Electrical Diagram
220-230V 1N~
TH2-30NS
380-415V 2N~
V
U
N
G
380-415V 3N~
TH4-60NS
50/60Hz
W
V
U
N
N
G
380-415V 3N~
TH6-80NS
50/60Hz
W
V
U
N
N
G
TH3-35NS
380-415V 3N~
50/60Hz
W
V
U
N
N
G
380-415V 3N~
TH4-80NS
50/60Hz
W
V
U
N
N
G
380-415V 3N~
50/60Hz
W
V
U
N
N
G
TH3-45NS
380-415V 3N~
50/60Hz
W
V
U
N
N
G
380-415V 3N~
50/60Hz
W
V
U
N
N
G
TH6-90NS
TH3-60NS
380-415V 3N~
50/60Hz
W
V
U
N
N
G
TH5-90NS
220-240V 3~
220-240V 1N~
50/60Hz 50/60Hz
W W
L3
L
V V
U U
L2
N N
N
N L1 N
G G
7
