schwa-medico Instruction Manual - AS SUPER 4 digital

Setting the intensity

Start the stimulation by increasing the intensity with the ▲ key of the
channel(s) connected to the needles/electrodes.
Press the ▲ key to increase the intensity.
Press the ▼ key to decrease the intensity.
The intensity of each channel is displayed on the screen.
The intensity can be set between 0 and 20 mA in steps of 0.1 mA.
By keeping the ▲▼ keys pressed, the intensity will increase/decrease more
rapidly.
The program starts after increasing the intensity. The clock symbol then
appears on the display and indicates the remaining therapy time.
The AS SUPER 4 digital constantly monitors the correct connection between
the needles, cables and device. The device does not permit the intensity to
exceed 4 mA if the circuit is not closed. The intensity then returns to 0. This
is also indicated by an acoustic signal. Please refer to the chapter "Malfunc-
tions".

Switching OFF the device

Once the program is completed, the intensities automatically return to 0. This
is also indicated by an acoustic signal. Press the key to switch OFF the
device. You can then remove the crocodile clips from the needles and remove
the needles from the patient's skin.

Pausing the stimulation

Press the E key during the running stimulation to pause the stimulation. The
word "PAUSE" then flashes on the display. Press the E key again to restart the
stimulation. If you do not restart the stimulation within 2 minutes, the device
switches OFF automatically.

Stopping the stimulation

Press the P key at any time to stop the stimulation. The intensity of all chan-
nels returns to 0. Press the key to switch OFF the device. You can then
remove the crocodile clips from the needles and remove the needles from the
patient's skin.
