Die head ........................................ Automatic-die head 1/2" – 2" or 2 SE die heads
Dies ............................................... 1/2" – 3/4", 1" – 2" (Optional 1/4" – 3/8" Art.-No. 56369)
Noise pressure level (L
Sound power level (L
The noise level during operation can exceed 85 dB (A). Wear hearing protection!
Measured values determined in accordance with EN 61029-1:2010.
Vibration total value .............................................................
The vibration level given in this information sheet has been measured in accordance with a
standardised test given in EN 61029 and may be used to compare one tool with another. It may
be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main applications of the tool.
However if the tool is used for different applications, with different accessories or
insertion tools or is poorly maintained, the vibration emission may differ. This may
significantly increase the exposure level over the total working period.
An estimation of the level of exposure to vibration should also take into account the
times when the tool is switched off or when it is running but not actually doing the
job. This may significantly reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator from the effects of vibra-
tion such as: maintain the tool and the accessories, keep the hands warm, organisa-
tion of work patterns.
3

Function of the Unit

3.1 Overview
1 Pipe cutter
2 Dies
3 Internal deburrer
4 Tool carriage
5 Oil drainage screw
6 Feeder hand wheel
7 Centring chuck
3.2

Functional description

Threads are cut or turned on workpieces such as pipes or rods in the thread-tapping machine
ROPOWER 50 R.
The machine consists of:
- a drive motor that rotates the centring chuck
- a clamping chuck for securing the workpiece
- a pipe cutter for cutting the workpiece to length
- an internal deburrer
- a thread-tapping head for making a thread on the workpiece
- an oil pump that lubricates and cools with thread-tapping oil
- a tool carriage guided on both sides with a toothed feed
- a chip collecting and oil trough
- a safety pedal
- a coasting restrictor
4

Preparations for operation

20
) .............. 85 dB (A) ¦ K
pA
) ................ 96 dB (A) ¦ K
WA
< 2,5 m/s
ENGLISH
3 dB (A)
pA
3 dB (A)
WA
2 2
¦ K= 1,5m/s
8 Clamping chuck
10 T-handle
11 Locking lever
12 Selector pin
13 Selector block
14 Cam plate
15 Locking lever
