7. Going into operation

7. Going into operation
7.1 Insert the batteries
The dispenser has to be removed from the mounting plate
(see removal of the mounting plate 6.2), the back of the
dispenser must be easily accessible.
If the dispenser is not used for a longer period than 3 months, the
•
batteries should be removed in order to prevent unwanted discharge.
33
plus
IMP Touchless - Instruction manual
Open the cover of the battery case. To do that release the
lower strap of the cover which is clipped in below the
base angle. Then unhinge the cover and put it aside.
Now insert the batteries into the dispenser.
Please pay attention to the correct polarity.
Keep the sequence as follows!
Open face shield.
4 2
3 1
5
