The device must only be installed in the marked operating position (arrow upwards).
The maximum service life must never be exceeded.
Please consider that unauthorized modifications on the device are forbidden due to safety reasons!
Never remove the serial barcode from the device as this would make the guarantee void.
If this device will be operated in any way different to the one described in this manual, the product may suffer
damages and the guarantee becomes void. Furthermore, any other operation may lead to dangers like short-
circuit, burns, electric shock, crash etc.
4. DESCRIPTION
4.1 Features
For problem-free installations
Makes the installation of your lighting system really easy • Installed directly at the stand or crossbeam • Fully
wired • With 4 spot connections • Outputs via 4 flap safety sockets • Connection via 16-pin In/Out-Harting-
socket
4.2 Description of the device
4.2.1 Frontpanel
1
2
Fixation point
CH-1
5 kg
Safety rope
(1) Fixation point
(2) Power outlet
(3) Attachment eyelet
(4) Industrial input plug
(5) TV pin
(6) Industrial output socket
3
4
Fixation point
CH-2
5 kg
5
6
Occupation:
Fixation point
CH-1
1+9
CH-2
2+10
CH-3
3+11
CH-4
4+12
CH-3
CH-5
5+13
CH-6
6+14
5 kg
Max. centered
braceload: 25 kg
14
Typ/Type: AB-410X
Spannungsversorgung/Power supply: 230 V AC, 50 Hz ~
Vor Gebrauch Anleitung lesen. Gerät
Fixation point
Max. Gesamtleistung/Max. power output: 14490 W
vor Feuchtigkeit schützen! Gefahr eines
Max. Gesamtstrom/Max. total current: 63 A
elektrischen Schlages, niemals das
Max. Nennleistung/Kanal/Max. output/channel: 3680 W
Gerät öffnen! Im Geräteinnern befinden
Max. Nennstrom/Kanal/Max. current/channel: 16 A
sich keine zu wartenden Teile. Wartungs-
Max. Tragfähigk./Aufnahmepunkt/Max. load/fixat. point: 5 kg
und Servicearbeiten nur durch autorisier-
ten Fachhandel! Sicherungsseile für
Max. verteilte Tragfähigkeit/Max. spaced braceload: 30 kg
Lasten und Eigensicherung verwenden!
Max. zentrale Tragfähigkeit/Max. centered braceload: 25 kg
Beim Installieren der Leuchten Warnhin-
CH-4
Gewicht/Weight: 4 kg
weise beachten!
Inspektionen/Inspections: 1/y
Read user manual before use. Keep away
Max. Nutzungsdauer/Max. service life: 10 y
from moisture! Risk of electric shock,
Baujahr/Year of construction: 2002
never open the housing! There are no
Safety rope
5 kg
serviceable parts inside the device. Main-
tenance and service operations only by
eurolite
MADE IN CHINA
®
loads and for device itself! Respect all
authorized dealers. Use safety-ropes for
UP
warnings when rigging the luminaires!
