BEDIENUNGSANLEITUNG
4-channel Alubar
Fixation point
CH-1
5 kg
Safety rope
Für weiteren Gebrauch aufbewahren!
Keep this manual for future needs!
USER MANUAL
AB-46
Fixation point
Pin-occupation
Pin 1: Channel 1
Pin 2: Channel 2
Pin 3: Channel 3
CH-2
Pin 4: Channel 4
Pin 5: Neutral
5 kg
Pin 6: Neutral
Max. centered
braceload: 25 kg
Fixation point
Typ/Type: AB-46
Vor Gebrauch Anleitung lesen. Gerät
Spannungsversorgung/Power supply: 230 V AC, 50 Hz ~
vor Feuchtigkeit schützen! Gefahr eines
Max. Gesamtleistung/Max. power output: 4600 W
elektrischen Schlages, niemals das
Max. Gesamtstrom/Max. total current: 20 A
Gerät öffnen! Im Geräteinnern befinden
Max. Nennleistung/Kanal/Max. output/channel: 1150 W
sich keine zu wartenden Teile. Wartungs-
Max. Nennstrom/Kanal/Max. current/channel: 5 A
und Servicearbeiten nur durch autorisier-
Max. Tragfähigk./Aufnahmepunkt/Max. load/fixat. point: 5 kg
ten Fachhandel! Sicherungsseile für
CH-3
Max. verteilte Tragfähigkeit/Max. spaced braceload: 30 kg
Lasten und Eigensicherung verwenden!
Max. zentrale Tragfähigkeit/Max. centered braceload: 25 kg
Beim Installieren der Leuchten Warnhin-
Gewicht/Weight: 3.5 kg
weise beachten!
Inspektionen/Inspections: 1/y
Read user manual before use. Keep away
Max. Nutzungsdauer/Max. service life: 10 y
from moisture! Risk of electric shock,
5 kg
Baujahr/Year of construction: 2002
never open the housing! There are no
Safety rope
serviceable parts inside the device. Main-
tenance and service operations only by
eurolite
MADE IN CHINA
authorized dealers. Use safety-ropes for
UP
®
loads and for device itself! Respect all
warnings when rigging the luminaires!
Reproduction prohibited!
Fixation point
CH-4
5 kg
©
Copyright
Nachdruck verboten!
