4. Design and function
Recalibration
Select the required certificate from the database. Only completed certificates (marked with a green tick) can be recalibrated. A
copy of the certificate will be created and opened, and when the [Measuring results] table is pressed, the measurement can
be restarted.
EN
Upload
With "Upload", a calibration routine can be defined and installed on the CPH7000.
All parameters must be entered. The measuring points and measurement series can be specified by default. With upload, the
calibration routine will be created and uploaded to the CPH7000.
Download
The calibrations stored on the CPH7000 can be downloaded and archived using "Download".
▶
Select reference instrument and click on "Download".
⇒
Then the available data sets are shown in the selection window.

4.2.3 WIKA-Cal - Log-Template

The following options are available with the "Log-Template":
New log
The "New Log" function opens a new logger protocol.
Following the input of all parameters, the "Wireless address" line must be pressed in the communication window. Select the
CPH7000 used and confirm.
By pressing the [Measuring results] graphic, the logger process is started.
16 WIKA operating instructions portable process calibrator, model CPH7000
