3. Safety
3.6

Labelling, safety marks

3.6.1 Product label for process calibrator model CPH7000

The product label is located on the rear, in the upper part.
Approval-related data for radio approval
1
Safety instructions for radio approval
2
Permissible ambient temperature
3
Serial number
4
Date of manufacture (month-year)
5

3.6.2 Product label for reference pressure sensor model CPT7000

Serial number
1
Serial number external sensor
2
Date of manufacture (month-year)
3
Accuracy
4
Pressure measuring range
5
Model
6
Symbols
Before mounting and commissioning the instrument, ensure you read the operating instructions!
Instruments bearing this mark comply with the relevant European directives.
This marking on the instruments indicates that they must not be disposed of in domestic waste. The disposal is
carried out by return to the manufacturer or by the corresponding municipal authorities.
WIKA operating instructions portable process calibrator, model CPH7000
9
8
7
6 5
6
5
4
4 3 2
Accuracy
6
Input signals
7
Pressure measuring range
8
Model
9
1
1
2
3
11
EN
