Select The Name Of Current Folder; Playback Memos - Trotec EC-series Bedienungsanleitung

<DIR> GZSAT001
Open SAT00001.SA
2. If the image you wish to open or delete is not in the
current folder, press the [UP] arrow on the omni selector
until the following message appear.
.. <DIR>
Enter or Delete
3. Press the C key, then pass the S key, you can activate
the image.

Select the name of current folder

1. Press the MENU/ENTER key.
2. Press the ▲ Up and
Down ▼ arrow on the
omni selector to select
the [Set-up] menu,
then press the MENU/
ENTER key.
3. Press the ▲ Up and
Down ▼ arrow on the
omni selector to se-
lect the [Others]
menu, then press the
MENU/ENTER key.
4. Press the ▲ Up and
Down ▼ arrow on
the omni selector
to select the [Directory
name] menu, then
press the Left and
Right arrow to select
the folder.

Playback Memos

1. Install the Blue
tooth (optional) headset
and open an image.
2. Press MENU/ENTER key
then press Left or Right
arrow on the omni se-
lector to select the [File] menu.
3. Press ▲ UP and
DOWN ▼ arrow on
the omni selector to
select [Voice Play],
then press the Menu/
Enter key. A [Playing
Record]
will appear on the LCD monitor.
4. You can terminate the playback of voice comment by
pressing C key.
Erasing Images
2. Press
key then press ▲ Up
and Down ▼ arrow on
the omni selector to se-
lect the [File] menu.
2. Press ▲ UP and
DOWN ▼ arrow on
the
to select [Delete], then
press the Menu/Enter
key.
3. Select an image, then
press MENU/ENTER key
to delete the selected
image.
4. Press the C key to exit.
Operating manual – Infrared camera
message
Please note that erased images cannot be
recovered. Exercise caution before erase
an image!
MENU/ENTER
omni selector
B - 18
