2. Press Up ▲ and Down
▼ arrow on the omni
selector to select [Ma-
nual adj.], then press
MENU/ENTER key.
3. Setting measurement range.
• Press the Up ▲ or
Down ▼ arrow on
the omni selector to
select range.
• Press the Left
Right arrow on
the omni selector to set the measurement range.
• This option is unavailable when the image is frozen.
4. Selecting the measuring range when using optional
lenses
• Having selected
the box for the
measuring range,
press the keys ▲
UP/DOWN ▼ si-
multaneously
set the tempera-
ture range for the lens in use.
Type Zero A
Lens 20° 12,8°
5. Having completed this step, press the MENU/ENTER
key to close the window.
Freezing / Activating an image
You can activate / freeze a thermal image by pres-
sing the S key on the selector.
1. Check that the IR came-
ra is in null mode.
2. Press the S key, then
the image is freezing.
or
to
B C D
38° 3,8° 6,4°
Operating manual – Infrared camera
3. Press the S key again, then the image is active.

Setting analysis parameters

1. Press the MENU/ENTER key.
2. Press Up and Down
arrow on the omni se-
lector to select [Ana-
ysis],then press the
MENU/ENTER key.
3. Setting the analysis
parameters
• Press the arrow UP
▲ /DOWN ▼ on the
selector to get to the
menu item "Object
Set-up".
• Press either the ▲ UP / DOWN ▼ or
RIGHT key on the omni-selector to set the values.
4. After this operation,
press the
ENTER key to save
changes, or press the
C key close menu
window without sa-
ving.
E
9°
MENU/
LEFT /
B - 12
