Installation dimensions (mm) | Circuit diagram
Behind partition
Shower tray connected
5
4
Pos
Description
1
Removable panel KBN: ALPRO
2
Partition frame
3
Venting insert KBN: ABSVIS
4
Shower tray
*
* During normal operation the valve is energized by 230 V AC (2A) and thus
remains opened. In case of high water level or power failure the valve will
close (water stop).
MAX. 350
2%
DN 50
6
Figure 15 (2)
5
6
7
21. Circuit diagram
Figure 16
38
3
DN 50
DN 50
7
Secondary vent pipe option
Discharge flap valve
Evacuation pipe
50
