Materials | Application

5.3 Materials

Cutting system
Tank casing
Pump casing
Impeller
Seals
Motor shaft
Performance curve
Dimensions
>
FLOWCB is a pumping station designed for direct connection to one toilet
> Installed above ground, directly behind toilet or behind partition wall
> For light domestic use and with the requirement that an additional toilet must
be installed separately above the flood level
> Operates in combination with a cistern of minimum 6 litres flushing volume.
Proper operation is not guaranteed at lesser volumes e. g. when using the light
flush in a dual-flush cistern
>
In accordance with DIN EN 12050-3 only a hand basin, a bidet and a shower
tray can be connected in addition to the toilet. Connection of a washing
machine, dishwasher or bath is not allowed
> The tank must be in the same room as the utilities to which it is connected
>
For domestic sewage and wastewater, with and without faeces, and without
harmful substances, in accordance with DIN 1986 Part 3
>
Use only cleaning products with a pH of 4 – 10 when cleaning utilities
connected to the tank
>
Not suitable for corrosive or flammable materials, oils, gaseous and explosive
media, disposal of condensation from condensing boilers, or where the water
has been filtered through a water softening system
> For liquids with a temperature of max. 40 °C, or 60 °C for up to 5 minutes
> The noise emission value is less than 70dB (A)
Special stainless steel
Polypropylene
Polypropylene
Polyamide
NBR/EPDM
Stainless steel 1.4028 (AISI 420)
See page 36, fig. 13
See page 37

6. Application
