Bild. Nr.3a Schema -Kessel VIADRUS HERCULES U 26 3 – 7 Gl.
8 - Oberteil d. Mantels
9 – Stirnfläche d. Mantels
10 –Seitenteil d. Mantels
11 – Betätig. d. Rauchklappe
12 – hinteres Glied
Bild. Nr. 3b Schema - Kessel VIADRUS HERCULES U 26 8 – 10 Gl.
13 – Rauchgasaufsatz
14 – Mittelglied
15 – Mittelglied m. Aussparung
16 – vorderes Glied
17 – Kipprost
