SAFETY PRECAUTIONS

WARNING:
TO PREVENT FIRE OR SHOCK HAZARD, DO
NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE.
IMPORTANT
The wires in this mains lead are coloured in accordance
with the following code:
GREEN - AND - YELLOW:
EARTH
BLUE:
NEUTRAL
BROWN:
LIVE
As the colours of the wires in the mains lead of this appara-
tus may not correspond with the coloured markings identi-
fying the terminals in your plug. proceed as follows.
The wire which is coloured GREEN-AND-YELLOW must
be connected to the terminal in the plug which is marked
with the letter E or by the safety earth symbol
oured GREEN or GREEN-AND -YELLOW. The wire which
is coloured BLUE must be connected to the terminal which
is marked with the letter N or which is coloured BLACK.
The wire which is coloured BROWN must be connected
to the terminal which is marked with the letter L or col-
oured RED.
WARNING-THIS APPARATUS
MUST BE EARTHED
Changes or modifications not approved by JVC could void
the user's authority to operate the equipment.
This unit is designed for professional use only.
This equipment is in conformity with the provisions and protection requirements of the corresponding European Directives. This
equipment is designed for professional video appliances and can be used in the following environments:
• residential area (in houses) or rural area
• commercial and light industry; e.g. offices or theatres
• urban outdoors
In order to keep the best performance and furthermore for electromagnetic compatibility we recommend to use cables not exceed-
ing the following length:
Port
CAMERA CABLE
AC INPUT
COMPOSITE VIDEO
Y/C OUTPUT
B/B-Y OUTPUT
G/Y OUTPUT
• The inrush current of this apparatus is 3.1 amperes.
Caution :
Where there are strong electromagnetic waves or magnetism, for example near a radio or TV transmitter, transformer, motor,
etc., the picture may be disturbed. In such case, please keep the apparatus away from the sources of the disturbance.
E-2
or col-
Cable Lenght
Exclusive Cable 100 meters
AC Power Cable 2 meters
Coaxial Cable 10 meters
Exclusive Cable 5 meters
Coaxial Cable 10 meters
Coaxial Cable 10 meters
INTRODUCTION
Thank you for purchasing this JVC product.
Before operating this unit, please read the instructions care-
fully to ensure the best possible performance.
These instructions are for RM-P210E.
Contents
INTRODUCTION
Features ........................................................................... 3
Provided Accessories and Documents ............................ 3
Precautions for Proper Use ............................................. 3
Controls, Connectors and Indicators ............................... 4
Front panel ................................................................... 4
Rear panel .................................................................... 6
CONNECTION
Example of Basic Connection .......................................... 7
Example of RM-P210 (Connection of 2 units) ................. 8
Camera Setup .................................................................. 9
Turning the Power ON .................................................... 10
PREPARATIONS AND MAIN FUNCTIONS
Camera Cable Length Setup ......................................... 11
Adjustments for Genlock Operation ............................... 12
Intercom ......................................................................... 13
Camera Operator Call .................................................... 13
Tally Input ....................................................................... 13
Function Keys ................................................................ 14
CAMERA ADJUSTMENTS
Shutter Speed Adjustment ............................................. 15
Gain Adjustment ............................................................ 15
Iris Adjustment ............................................................... 16
White Balance Adjustment ............................................. 17
MENU OPERATION
Flow of Menus ............................................................... 18
Menu Setup Method ...................................................... 19
GENLOCK Menu ........................................................... 20
CABLE Menu ................................................................. 20
FILE Menu ..................................................................... 21
PROCESS Menu ........................................................... 22
OPERATION Menu ........................................................ 24
LCD MODE Menu .......................................................... 25
SYSTEM RESET Menu ................................................. 26
GENERAL
Warning Messages ........................................................ 27
Error Messages ............................................................. 27
Functions Available Depending on Camera Models ...... 28
Troubleshooting ............................................................. 29
Specifications................................................................. 30
Port
R/R-Y OUTPUT Coaxial Cable
GENLOCK INPUT Coaxial Cable
AUX VIDEO INPUT Coaxial Cable
INTERCOM JACK Cable of Intercom
INTERCOM (H, C, G) Single wire
TALLY Single wire
Cable Lenght
10 meters
10 meters
10 meters
2 meters
5 meters
5 meters
