CONTROL PANEL

1. Fridge temperature LEDs
2. On/Stand-by icon/button
3. "6th Sense Fresh Control" / "Green Intelligence
ProFresh" icon
4. Eco Night icon/button
5. Freezer temperature LEDs
6. Fridge temperature / Fast Cool (press 3 sec.) button
7. Black Out icon
8. Reset button / Alarm icon
9. Key Lock button
10. Freezer temperature / Fast Freeze (press 3 sec.) button
"ZERO DEGREES" BOX
(depending on the model)
The "Zero Degrees" box is specifically designed to maintain a
low temperature and a suitable humidity level, in order to
keep foods fresher for longer (e.g. meat, fish, fruit and winter
vegetables).
Activating and deactivating the box
To activate/deactivate the box, press
the button as illustrated in the figure.
When the box has been
activated, the symbol lights up.
The temperature inside the box, when active, is
approximately 0°. The following factors are vital for the
"Zero Degrees" box to work properly:
- the refrigerator compartment must be switched on
- the temperature of the refrigerator compartment must be
between +2°C and +5°C
- the box must be inserted to enable activation
- no special functions must have been selected (Standby,
Cooling-Off, Vacation – where applicable).
If one of these special functions has been selected, the "Zero
Degrees" box must be deactivated manually, and any fresh
food inside it removed. If manual deactivation does not take
place, the box will be deactivated automatically after 8 hours.
D GB F NL E
PRODUCT SHEET
P I GR S N
Note:
- if the symbol does not light up when the box is activated,
check that the box is properly inserted; if the problem
persists, contact your nearest authorized After-sales
Service
- if the box is active and the drawer open, the symbol on
the control panel may be deactivated automatically. If the
drawer is inserted, the symbol will become active again
- irrespective of the state of the box, a slight noise may be
heard: this is normal and is not a cause for concern.
- when the box is not active, the temperature inside it
depends on the general temperature inside the
refrigerator compartment.
In this case, we recommend it is used to store fruit and
vegetables which are not sensitive to cold temperatures
(fruits of the forest, apples, apricots, carrots, spinach, lettuce,
etc.).
Important: when the function is activated and there are
foodstuffs with a high water content, condensation may form
on shelves. In this case, disable the function temporarily.
Removing the "Zero Degrees" box:
The "Zero Degrees" box can be
removed to create more space
inside the refrigerator. In this case
proceed as follows:
- switch off the box
- pull out the drawer and the
white plastic shelf underneath
the box.
Note: the upper shelf and the side supports cannot be
removed.
To restore "Zero Degrees" box operation, make sure you
replace the white plastic shelf underneath the box before
inserting the drawer and reactivating the function. To
optimise energy consumption, we recommend you
deactivate the "Zero Degrees" box and remove it. Clean the
box and all its parts regularly, using a cloth and a solution of
warm water and neutral detergent specifically formulated for
refrigerator interiors (take care not to immerse the white
plastic shelf underneath the box in water).
Before cleaning the box (including the outside),
remove the drawer so as to disconnect the box from
the electricity supply.
Never use abrasive detergents.
FUNCTIONS
On/Stand-by
This function turns On/Stand-by both the refrigerator
and freezer compartments. To put the product in Stand-
by, press & hold the
seconds. All the icons turn off except
icon back light to indicate that the appliance is in Stand-
by. When the appliance is in Stand-by, the light inside the
refrigerator compartment does not work. Remember
that this operation does not disconnect the appliance
from the power supply. To switch the appliance on again,
simply press the
Fridge Temperature
To adjust the Fridge Temperature, press the
button. The Fridge Temperature can be adjusted
DK FIN PL CZ SK
On/Stand-by button for 3
On/Stand-by
On/Stand-By button.
