PARTS
1. Robot vacuum cleaner
2. Charging and emptying station
3. Side brush
4. Mopping pads
5. Ramp
ROBOT VACUUM CLEANER
6. Top cover
7. Bumper
8. On/off button
9. Charging button
10. Indicator light
11. Laser sensor
12. Charging contacts
13. Dust discharge port
14. Water inlet
15. Swivel wheel
16. Side brush
17. Side wheel
18. Suction nozzle with rotating brush
19. Dust container
DUST CONTAINER
20. HEPA filter with pre-filter sponge
20
64
3
1
13
14
16
17
