Press the MODE button until the display shows "DMX-2CH". You can now set the desired DMX mode (Ch-1
or Ch-2) via the UP or DOWN buttons.
Press the MODE button until the display shows "DMX***". You can now set the desired address (001 - 512)
via the UP or DOWN buttons.
Controlling:
After having addressed EUROLITE LED Profile Spot 100W WW, you may now start operating it via your
lighting controller.
DMX-protocol
Channel 1 – Dimmer: Increasing brightness
Value:
000 – 255
Channel 2 – Strobe: Increasing speed
Value:
000 – 015
016 – 027
028 – 039
040 – 051
052 – 063
064 – 075
076 – 087
088 – 099
100 – 111
112 – 123
124 – 135
136 – 147
148 – 159
160 – 171
172 – 183
184 – 195
196 – 207
208 – 219
220 – 231
232 – 243
244 – 255
CLEANING AND MAINTENANCE
The operator has to make sure that safety-relating and machine-technical installations are inspected by an
expert after every four years in the course of an acceptance test.
The operator has to make sure that safety-relating and machine-technical installations are inspected by a
skilled person once a year.
The following points have to be considered during the inspection:
1) All screws used for installing the devices or parts of the device have to be tighly connected and must not
be corroded.
2) There must not be any deformations on housings, fixations and installation spots (ceiling, suspension,
trussing).
3) The electric power supply cables must not show any damages, material fatigue (e.g. porous cables) or
sediments. Further instructions depending on the installation spot and usage have to be adhered by a
skilled installer and any safety problems have to be removed.
Function:
0 – 100%
Function:
Off
Speed 1
Speed 2
Speed 3
Speed 4
Speed 5
Speed 6
Speed 7
Speed 8
Speed 9
Speed 10
Speed 11
Speed 12
Speed 13
Speed 14
Speed 15
Speed 16
Speed 17
Speed 18
Speed 19
Speed 20
22/23
00076260.DOC, Version 1.1
