Technical Specifications - EuroLite LED Profile Spot 100W WW Bedienungsanleitung

We recommend a frequent cleaning of the device. Please use a moist, lint-free cloth. Never use alcohol or
solvents!
The lens has to be replaced when it is obviously damaged,
so that its function is impaired, e. g. due to cracks or deep scratches!
The objective lens will require weekly cleaning as smoke-fluid tends to building up residues, reducing the
light-output very quickly.
There are no serviceable parts inside the device. Maintenance and service operations are only to be carried
out by authorized dealers.
Should you need any spare parts, please use genuine parts.
If the power supply cable of this device becomes damaged, it has to be replaced by authorized dealers only
in order to avoid hazards.
Should you have further questions, please contact your dealer.

TECHNICAL SPECIFICATIONS

Power supply:
Power consumption:
Number of DMX channels:
DMX-512 connection:
Maximum ambient temperature T
Maximum housing temperature T
Minimum distance from flammable surfaces:
Minimum distance to lighted object:
LED type:
Number of LEDs:
Dimensions (LxWxH):
Weight:
Accessories:
Color filter frame for Profile Spot 650W
Barn doors for Profile Spot 650W
Four-way blade 4pcs for Profile Spot 650W
Iris for LED Profile 100W WW
Saveking Safety bond 3x600 black
EUROLITE TPC-10 Coupler, black
EUROLITE STV-20 Follow spot stand
Please note: All information is subject to change without prior notice. 22.10.2014 ©
DANGER TO LIFE!
Disconnect from mains before starting maintenance operation!
:
a
(steady state):
C
CAUTION!
90-240 V AC, 50/60 Hz ~
120 W
2
3-pin XLR
45° C
55° C
0.5 m
0.1 m
COB 100 W
1
590 x 260 x 320 mm
9 kg
Article No.:
40001962
40001963
40001964
40001995
58010252
59006858
59007120
23/23 00076260.DOC, Version 1.1
