Strobe
Press the MODE button until the LCD display shows "Col Strob Speed**".
Via the UP or DOWN buttons, you can set the desired strobe speed. You can choose from 20 speeds, with
increasing rate. (See following graphic)
Value:
000 – 015
016 – 027
028 – 039
040 – 051
052 – 063
064 – 075
076 – 087
088 – 099
100 – 111
112 – 123
124 – 135
136 – 147
148 – 159
160 – 171
172 – 183
184 – 195
196 – 207
208 – 219
220 – 231
232 – 243
244 – 255
Master/Slave
Set the Master device to Dimmer or Strobe mode and set each Slave device to the same DMX address
"001".
Focusing (back button)
Step 1: Loosen the focus button on the underside of the device, toward the back.
Step 2: Adjust the focus by sliding the back lens-housing forward or backward.
Step 3: Tighten the focus button.
Zooming (front button)
Step 1: Loosen the zoom button on the underside of the device, toward the front.
Step 2: Adjust the zoom by sliding the front lens-housing forward or backward.
Step 3: Tighten the zoom button.

DMX MODE

Addressing

Depending on the DMX-mode, each EUROLITE LED Profile Spot 100W WW occupies DMX-channel 1 or 2.
If you select Mode "Ch-1" for example, the device occupies the DMX-channel for Dimmer control.
The Control Board allows you to assign the DMX starting address, which is defined as the first channel from
which the LED Profile Spot 100W WW will respond to the controller.
Function:
Off
Speed 1
Speed 2
Speed 3
Speed 4
Speed 5
Speed 6
Speed 7
Speed 8
Speed 9
Speed 10
Speed 11
Speed 12
Speed 13
Speed 14
Speed 15
Speed 16
Speed 17
Speed 18
Speed 19
Speed 20
