Relative Measurement; Units Of Measure - LaserLiner LuxTest-Master Handbuch

Relative measurement

5
After switching on the device, activate relative
measurement by pressing the „REL/PEAK"
button. The value last displayed will be set as
the reference value and it now shows the
difference with respect to the set reference
value. The relative measurement can be carried
out both in the automatic as well as in the
manual measuring range. This function is
deactivated by pressing the „REL/PEAK"
button again.
Peak measurement
6
After switching on the device, activate peak
measurement by pressing the „REL/PEAK" button.
This function increases the response of the sensor,
thus enabling it to register quick changes in light
levels. Peak measurement is only possible in the
manual measuring range. Set the corresponding
measuring range as described in Step 4. Press and
hold the „REL/PEAK" button to deactivate this
function.
!
The peak value remains visible on the display. Measured values lower
than the peak value will not be displayed.

Units of measure

7
The measured values can be displayed in Lux and
FC (foot-candles). Press the „UNIT" button to
change the unit of measure.
LuxTest-Master
10
5
0
2 sec
5
0
5
0
15
20
09
GB
