Technical Data - LaserLiner LuxTest-Master Handbuch

Technical data

Measuring range
Accuracy
Sensor
Spectral range
LC display
Sampling rate
Standard
Voltage supply
Operating temperature
Max. relative humidity
Dimensions (W x H x D)
Weight
Technical revisions reserved. 02.12
EU directives and disposal
This device complies with all necessary standards for the free movement
of goods within the EU.
This product is an electric device and must be collected separately for
disposal according to the European Directive on waste electrical and elec-
tronic equipment.
Further safety and supplementary notices at: www.laserliner.com/info
LuxTest-Master
20.00 lux; 200.0 lux; 2,000 lux; 20,000
lux; 200,000 lux
3% V(λ) adaptation
2% cosine correction
Silicon photodiode
320 nm...730 nm
3 1/2 positions with analogue bargraph
2 measurements/second
DIN 5032-7 Type B
1x 6F22 9V
-10 °C ... 50 °C
85% (no condensation)
89 mm x 190 mm x 42.5 mm
250 g (including batteries)
11
GB
