1. Assemble the base by joining the two
pieces using the fixing hooks until they
are properly fitted.
4
1. Ventilation Mode Indicators
2. Speed Indicators
3. Timer Indicators
4. Power On/Off Button
8
E NGL I SH

ASSEMBLY INSTRUCTIONS

CONTROL PANEL

1
5
2. Place the base on the bottom of the main
body of the device and secure it using the
four screws supplied, making sure they
are properly tightened.
2
1h 2h 4h
6 7
5. Mode Button
6. Speed adjustment button
7. Timer Button
8. Rocker Button
3
