Description Of Functions; Overview; Technical Data - Parkside Pdra 20-Li D4 Originalbetriebsanleitung

GB MT
• Rechargeable battery and charger with
instruction manual

Description of functions

Please refer to the descriptions below for in-
formation on how the operating elements
work.

Overview

The illustrations for the device
can be found on the front fold-
out page.
1 Locking mechanism
2 Switch lever
3 Trigger gun
4 Coupling (Water connection)
5 Battery holder
6 Cleaning agent tank
7 Cleaning agent nozzle
8 Nozzles (Adjustable)
9 Lance
10 Quick connector
11 Suction hose
12 Filter basket
13 Mesh bag
14 Cleaning agent
15 Battery release
16 Battery
17 Charge level indicator
18 Button (Battery)
19 Charger

Technical data

Cordless Pressure Washer PDRA 20-Li D4
Rated voltage U ..................................20 V ⎓
Protection type ....................................... IPX0
Weight (without battery/Accessories/
Detergent) .......................................... ≈1.3 kg
Long suction hose ................................... 6 m
Operating pressure (p) ......................2,5 MPa
Max. inlet pressure (p
Max. inlet temperature (T
Max. rated flow rate (Q
Max. suction height ................................. 3 m
Sound pressure level (L
......................................... 74.2 dB; K
18
) ............. 0.5 MPa
in;max
) ............30 °C
in;max
) ..............2,5 l/min
max
)
pA
=3 dB
pA
Sound power level (L
– Measured ................85.0 dB; K
– Guaranteed ........................................89 dB
Vibration (a ) ............. 1.555 m/s²; K=1.5 m/s²
h
Temperature ........................................≤50 °C
– Charging .........................................4–40 °C
– Operation ....................................... 4–50 °C
– Storage .........................................15–25 °C
PARKSIDE Performance Smart battery
Smart PAPS 204 A1/Smart PAPS 208 A1/
Smart PAPS 2012 A1
– frequency band ..............2400–2483.5 MHz
– transmitted power ....................... ≤ 20 dBm
Levels of noise and vibration were determ-
ined according to the standards and regula-
tions in the declaration of conformity.
The vibration emission value has been meas-
ured according to a standardised testing
method and may be used for comparison
with another power tool. The indicated vibra-
tion emission value may also be used for an
introductory assessment of the exposure.
WARNING! The vibration emission value
whilst actually using the power tool may vary
from the given values depending on the type
and way in which the power tool is used.
Safety measures for the protection of the op-
erator are to be determined that are based
on an estimate of the exposure under real
operating conditions (for this, all parts of the
operating cycle are to be taken into account,
for example, times in which the power tool
is turned off, and those during which it is
turned on but running without a load).
X 20 V TEAM
The device is part of the X 20 V TEAM
series and can be operated with batteries
of the X 20 V TEAM series. Batteries of the
X 20 V TEAM series may only be charged
using chargers of the X 20 V TEAM series.
We recommend that you operate this ap-
pliance with the following batteries only:
PAP 20 B1, PAP 20 B3, Smart PAPS 204 A1,
Smart PAPS 208 A1, Smart PAPS 2012 A1
We recommend charging these batteries
with the following chargers: PLG 20 C1,
PLG 20 C2, PLG 20 C3, PLG 201 A1,
PDSLG 20 B1, Smart PLGS 2012 A1
Rechargeable battery and charger technical
data: See separate manual.
)
WA
=2.60 dB
WA
