functions description
10 – OFFSET frequency shift
This setting concerns only the commercial versions UHF-/VHF-
COM.
The, for repeater operation, required tx-frequency shift is set in a
range between 0-90 MHz. The frequency steps can be changed
- 5/6.25/10/12.5/20/25/50 kHz.
11 – STEP frequency resolution
This setting is only of importance for the commercial radio version.
It defines the frequency resolution for the frequency shift.
12 – dSP channel display modes
The available display modes are channel number (CH), frequency
(FREQ) or channel
With the selections FREQ and NM, the channel number is addi-
tionally shown.
13 – bEEP warning tone
In active state (ON), every key operation is confirmed with an
acoustic signal, i.e. beep tone.
14 – TOT time-out-timer
In active state (1-30 min), the transmission is automatically deac-
tivated upon expiration of the set TOT time. With the PMR and
FreeNet Version, the TOT time is limited to 180 seconds due to re-
gulations.
15 – APO automatic power-off
In active state (30/60/120 min), the radio automatically powers off
after expiration of the selected time.
16 – SQL squelch
The squelch level determines the threshold for the required signal
strength to be audible in the speaker. The higher the value, the
stronger the signal has to be in order to pass the filter.
If the squelch is off, the typical, constant frequency noise is audible.
26
settings
0-90 MHz
5/6.25/10/12.5/20/25/50 kHz
CH / FREQ / NM
name (NM) (if programmed).
ON/OFF
OFF/1-30 min
OFF; 30/60/120 min
OFF/1-9
functions description
17 – AOP automatic power-on
In active state (ON), the radio powers on automatically once
power is applied.
This feature is useful if the radio should automatically be in ope-
ration mode once the vehicle is powered on.
18 – MIG microphone sensitivity
The communication with stations that transmit very strong signals
can cause feedback. In this scenario it is advantageous to reduce
the microphone sensitivity. The higher the value, the higher the
sensitivity.
19 – RESET default settings
The selection SETUP resets all settings to the individual software
programming.
The setting FACT resets all settings to the factory preset.
This feature can be deactivated by software. If deactivated the
settings SETUP and FACT are not offered any more.
Please make a data back-up of your individual programming.

External speaker jack

The MiCo is equipped with a 3.5 mm socket (9) at the rear panel to con-
nect an external speaker of 4-8 ohm impedance, e.g. TEAM TS-500.
At 4 ohms, the speaker load can be 4 watts. When the external speaker
is connected, the internal speaker is muted.
settings
ON/OFF
1-16
SETUP/FACT
27
