EdgeEndo EdgePack Gebrauchsanweisung Seite 4

Under ON state, shortly press "ON/OFF" button to change the preset tem-
perature of Work Tip. The preset temperature will change to the next with
the sequence 150℃→180℃→200℃→230℃ after each press. And then go
back to 150℃ after short press at temperature of 230℃.
150 180 200 230
Figure 1 Preset temperature
2) Heating button:
Under the ON state, connect the Work Tip, and press Heating button to start
heating. Release the Heating button to stop heating, followed by the fall of
Work Tip temperature.
Note: If press and hold the Heating button for more than 10 seconds, the de-
vice will stop heating. If need to continue heating, please release the Heating
button and press again.
3) Volume set
After power-on, press "ON/OFF" button and "Heating" button simultane-
ously to enter the voice volume setting mode, then short press the "ON/
OFF" button to select suitable voice volume, the last, short press the "Heat-
ing" button to exit the voice volume setting mode as shown in Figure 2.
4) Battery level:
The actual power of the battery is displayed in real time on the screen. When
the battery is fully charged, the power of the OLED display is displayed as
five grids. When the battery level is one grid, it indicates that the battery is
low and needs to be charged in time. When the battery level is displayed as
a space, it indicates that the battery is very low and needs to be charged im-
mediately.
Note: During normal use, try not to let the battery level reduced to space
status (completely no power) before charge, which will shorten the service
life of battery.
Warning:
If the device has not been used for more than one month, the battery needs
to be recharged. If the device is not in use for a long time, please be sure to
charge it at least once a month to protect the battery. The service life of bat-
tery of Heating and Packing Instrument will be shortened when it is in a low
battery state for a long time or when it leaves the charging base for a long
time.
2
