If in menu item 3 the shortest debouncing time of 1 ms is set, the maximum counting
frequency is at 500 Hz. On default setting of 5 ms the maximum counting frequency
is at 100 Hz.
Multiplicator/Divisor
In menu item 4 you can set a multiplicator and in menu item 5 a divisor between 1
and 1000 each.
The display corresponds to the number of pulses counted, multiplied by the multi-
plicator and divided by the divisor.
If a scaling is provided, let´s say with the factor 2.91, 291 is to be set as a multi-
plicator and 100 as a divisor.
Signal inputs
The inputs D7...D3 allow the following control functions:
Signal inputs
Stop counting
Stopping the display
Reset counter
Set counter to preset value
Reduction of display brightness
= rising edge of signal
Stop counter
With an L signal at input D3 the impulses are counted according to the setting in
menu item 1. With an H signal the counting inputs are locked [5].
Stopping the display
With an L signal at input D4 the display corresponds to the actual count of the
counter. With an H signal the display stops (hold function) while the counter
continues counting internally [6].
BAL S202 ZLR M0.22
D7
[5]
X
[6]
X
[7]
X
[8]
X
[9]
H
X = signal input without function
D6
D5
D4
L
L
L
L
L
H
L
L
L
L
X
X
X
D3
H
L
L
L
X
19
