If the 1 / X appears, it means that the data stream options haven't fully displayed. Swipe
the screen from bottom to top to display the remaining options. With 3 display modes
available, you can browse it with suitable ways :
• Figure: Displays parameters with wave patterns.
• Value: The default display mode shows parameters with numbers and lists.
Note: If the value of the data stream is not within the standard value range, the data stream will be
displayed in red.
• Combine: The graphs are presented together for users to make comparisons.
Note: different data flow options are marked in different colors.
How to check one wave pattern?
Click .
On the display page of wave patterns, the user can perform the following operations:
• Max./Min.: Click to set the highest / lowest value. Once the running value exceeds the
set value, the system will issue a warning.
• User-defined: Click "<" on the right side of the screen and then define the data stream
options to be checked by yourself.
Choose the data stream options to be checked (Note: Only a maximum of 4 data streams can
be displayed).
If you want to remove the wave pattern of some data stream, just deselect it.
How to check several wave patterns together?
Click [Combine] button and then the system will display the parameters of the selected
data streams with wave patterns.
