Parts List Pièces détachées
Ersatzteilliste パーツリスト
Parts List
En
Parts # Description
6203 Body Clip (8mm/Black/20pcs)
66796 Shock Mount Screw (CW+2/CCW+2)
67350 Shock Boots Set
67351 Shock End/Shock Spring Retainer Set
67353 6 Holes Shock Piston Set (1.2,/1.3/1.4mm)
67356 Stone Guard Set (Right/Left)
67376 Servo Arm Set
67380 Pivot Plate (RF/3deg)
67384 Front Suspension Block (FR)
67386 Front Hub Carrier Set (Right/Left/10deg)
67388 Front Spindle Set (Right/Left)
67390 King Pin Bushing (4pcs)
67391 Front Hinge Pin Plate
67392 Steering Post (2pcs)
67397 Steering Crank Set
67398 Steering Plate
67399 Steering Bushing (2pcs)
67402 Axle (1pc)
67404 Universal Joint Rebuild Kit
67405 Drive Shaft (90mm)
67409 Rear Shock Tower
67410 Shock Stand Off (2pcs)
67415 Suspension Pin 4X71mm Silver (Front/Inner)
67416 Suspension Pin 3X43mm Silver (Front/Outer)
67417 Suspension Shaft (Rear/Inner)
67418 Suspension Shaft (Rear/Outer)
67419 Differential Mount (2pcs)
67428 Spur Gear 48 Tooth
67438 Ball Bearing 8X14X4mm (2pcs)
67447 Big Bore Shock Spring (White/60mm/81Gf/2pcs)
67486 Wheel Hex Hub (2pcs)
67491 Steering Linkage Set
67492 17mm Wheel Nut (Black/4pcs)
67493 Ball 6mm (4pcs)
67499 Spiral Pinion Gear 10 Tooth
67510 Sway Bar (2.8mm)
67511 Sway Bar (2.4mm)
67514 Spacer 3X8.5X3mm (6pcs)
67515 Big Bore Shock Maintenance Set
67518 Universal Drive Shaft Set
67534 Ball 5.8X5.6mm (4pcs)
86598 Washer 13X16X0.2mm (10pcs)
94505 Cap Head Screw M4X12mm (10pcs)
94514 Cap Head Screw M4X35mm (10pcs)
94531 Flat Head Screw M4X15mm (Hex Socket/10pcs)
94554 Button Head Screw M4X10mm (Hex Socket/10pcs)
94675 Cap Head Screw M3.5X14mm (8pcs)
94676 Cap Head Screw M3.5X18mm (8pcs)
94677 Cap Head Screw M3.5X42mm (8pcs)
96705 Locking Washer M5 (20pcs)
100550 Pan Head Screw M5X8mm (Hex Socket/10pcs)
100551 Lock Nut M2.5 (4pcs)
100553 Washer M2.9X8X0.5mm (8pcs)
100554 Set Screw M3X14mm (4pcs)
100557 Flat Head Screw M3X16mm (Hex Socket/8pcs)
100558 Button Head Screw M3X4mm (Hex Socket/10pcs)
100559 Button Head Screw M3X14mm (Hex Socket/10pcs)
100914 Pinion Gear 15 Tooth (1M / 5mm Shaft)
103661 Motor Mount Set
103663 Cup Joint 5X13X20mm
103664 Drive Shaft 8X83mm
103668 Brace And Stiffener Set
103671 Flanged Lock Nut M3 (10pcs)
103675 Battery Holder Set
103680 Wire Guide
103682 Battery Strap 25X270mm (2pcs)
104123 Servo Saver Foam (4pcs) With Adjust Nut
104156 Servo Saver Set
107365 Big Bore Sport Shock Set (97mm/2pcs)
107367 4 And 5 Holes Shock Piston Set (1.2,/1.3/1.4mm)
107368 Front/Rear Differential Gear Set
Parts # Description
107369 Center Differential Gear Set
107372 Droop Screw M4X10mm (4pcs)
107373 Button Head Screw M2.5X10mm (Hex Socket/10pcs)
107374 Flat Head Screw M2.5X6mm (Hex Socket/10pcs)
107377 Waterproof Receiver Box Set
107379 Pivot Plate (RR/3Deg)
107380 Shock Tower (Front)
107383 Yokohama Geolandar Tires D Compound (2pcs)
107384 Ah-64 Wheel Black (42X83mm/2pcs)
107390 Front Suspension Arm Set
107391 Rear Suspension Arm Set
107394 Tie Rod Set
107422 Attk-8 Painted Body (Black)
107423 Main Chassis 4mm
107424 Drive Shaft 159mm
107425 Mud Flap Set (2pcs)
107426 Chassis Stiffener Set
107427 Rear Bumper Set
107428 Front Bumper Set
107429 Body Mount Set
HB62510 4 Way Wrench (1/8Th Scale)
HBC8008 Rear Wheel Hub L, R (Lightning Series)
HBC8009-1 Differential Case (Lightning Series)
HBC8019 Differential Housing (Lightning Series)
HBC8020-1 Rubber Sealed Bearing 8X16mm (4pcs) (Lightning Ser)
HBC8021 Differential Pads (Lightning Series)
HBC8022 Differential Shaft (Lightning Series)
HBC8023 O-Ring 6mm (Lightning Series)
HBC8064 Front & Rear Diff Axle Shaft (Lightning Series)
HBC8065 Rear Wheel Axle Shaft (Lightning Series)
HBC8069 90mm Center Shaft (Lightning Series)
HBC8071 Center Diff Axle Shaft (Lightning Series)
HBC8088 6X10mm Sealed Bearing (Lightning Series)
HBC8089 Ball For Steering Push Rod (Lightning Series)
HBC8090 Wheel Angle Adjuster (Lightning Series)
HBC8096 3X17mm Shaft (Lightning Series)
HBC8098 Fixing Ball For Upper Suspension (Lightning Series
HBC8099 Fixing Ball For Rear Suspension (Lightning Series)
HBC8101-1 Hard Steel Differential Gear Set (Lightning Series)
HBC8108 Front Stabilizer Set (Lightning Series)
HBC9010 43T Spiral Bevel Gear (Lightning Stadium)
Z084 Flat Head Screw M3X12mm (Hex Socket/10pcs)
Z086 Flat Head Screw M3X18mm (Hex Socket/10pcs)
Z087 Flat Head Screw M3X20mm (Hex Socket/10pcs)
Z150 Antenna Pipe Set
Z216 Button Head Screw M3X15mm (Hex Socket/4pcs)
Z224 Washer M3X8mm (10pcs)
Z242 E Clip E2mm (20pcs)
Z307 Flat Head Screw M4X10mm (Hex Socket/Thin Type/4pcs
Z352 Button Head Screw M3X8mm (Hex Socket/10pcs)
Z353 Button Head Screw M3X10mm (Hex Socket/10pcs)
Z354 Button Head Screw M3X12mm (Hex Socket/10pcs)
Z357 Button Head Screw M3X20mm (Hex Socket/10pcs)
Z492 Tp. Binder Head Screw M2.2X4.8mm (8pcs)
Z544 Cap Head Screw M3X12mm (6pcs)
Z547 Cap Head Screw M3X20mm (6pcs)
Z548 Cap Head Screw M3X22mm (12pcs)
Z562 Tp. Flanged Screw M3X10mm (Hex Socket/10pcs)
Z663 Lock Nut M3 (6pcs)
Z664 Lock Nut M4 (4pcs)
Z700 Set Screw M3X3mm (6pcs)
Z702 Set Screw M3X5mm (10pcs)
Z704 Set Screw M3X8mm (10pcs)
Z721 Set Screw M4X4mm (4pcs)
Z740 Set Screw M5X4mm Black (6pcs)
Z800 Spring Washer 3X6mm (20pcs)
Z901 Allen Wrench 1.5mm
Z903 Allen Wrench 2.5mm
Z904 Allen Wrench 2.0mm
Z905 Allen Wrench 3.0mm
