3.4

Function keys

Key
REC (3)
SETUP (4)
FAST/SLOW (5)
MAX/MIN (6)
LEVEL (7)
(8)
A/C (9)
HOLD (10)
On/Off (11)
4

Getting started

Insert the battery
To insert the battery, follow these steps:
1. Open the battery compartment on the back of the device.
2. Connect a 9V battery to the connector and place it in the battery compartment.
3. Close the battery compartment
If the battery voltage is low, an
battery when this happens.
Mains adaptor
If you want to use a mains adaptor, connect it to the power connector on the side of the device
(12). Make sure that the output voltage of the mains adaptor is 9 V DC.
The jack of the mains adaptor has to have the following dimensions:
Outer Ø: 3.5 mm
Inner Ø: 1.35 mm
Function
Data transmission enabled/disabled
Activate/deactivate auto power-off function
Press and hold before turning on the device to get to the
date/time settings
Switch between fast and slow sampling rate
Activate/deactivate max and min hold
Switch between the different measuring ranges
Activate/deactivate display backlight
Switch between A and C weighing of the sound level
Freeze/unfreeze the current reading on the display
Turn the sound level meter on/off
indication appears on the display. Please replace the
© PCE Instruments
22
