Set markers
After taking a measurement, you can set markers and compare different measuring points to
each other.
To do so, follow these steps:
1. Double-click at any point of the real-time graph.
2. The cursor now transforms into a violet vertical line. Move the line to the measuring
point you want to compare. The measuring value and time appear in the marker
indication (3) at "CursorA". Left-click on the measuring point in the graph to select it.
3. When you have set the first marker the cursor transforms into a green vertical line.
Select the position of the second marker. The measuring value and time appear in the
marker indication (3) at "CursorB". Left-click on the measuring point in the graph to
select it.
4. Once both markers are set, the software shows the MIN/MAX and average values, as
well as the number of measuring points between both markers.
Save data
To save the measured data, follow these steps:
Click on "File(F)" in the menu bar and select "Save as".
1.
2. A new window appears where you can set the saving path and file name.
Click on "Save" to save the data at the set location. The data is saved in *.txt format.
3.
Export data to Excel
To export the data to Excel click on "File(F)" and select "Export To Excel(E)". An Excel file with
the measured data opens automatically.
Print data
To print the measured data, follow these steps:
Click on "File(F)" in the menu bar and select "Print Graph(G)" to print out the graph or
1.
select "Print Data(D)" to print out the measured data as table.
2. A new window appears where you can adjust the printing settings.
Click on "OK" to print out the data.
3.
