5.2 OPERATING PANEL

• After turning on the ceramic glass cooktop, all displays briefly light up, indicating that
the cooktop is ready for use.
• The cooktop is equipped with electronic sensors that are activated by touching the
corresponding button for at least one second.
• Each time a sensor is activated, it emits an audible signal.
• Avoid placing objects on the sensor surface, as this may generate error signals.
• It is important to always keep the sensor surface clean.
6
4
1. On/Off key
2. Lock key
3. Pause key
4. Food warmer key & cooking zone
position
5. Cooking zone slider control - sensor field
6. Warming function display
7. Cooking zone power level display
8. Cooking zone timer display
9. Bridge function display
10. Cooking zone slider display
NOTE
Most of the keys shown here will only become visible with the hob switched on.
5.3 OPERATION PRINCIPLE OF THE COOKTOP EXTRACTOR
The cooktop extractor can be operated as an exhaust air or a recirculating air version. When
operated in exhaust air mode, remove the carbon filter from the appliance, as they are not
needed.
ASPIRATION MODE
The air suctioned away is purified by the grease filter and expelled into the open air
via a duct system. The exhaust air must not be expelled into:
• a smoke or exhaust gas flue that is in operation
• a shaft used for the aeration of rooms where fireplaces are installed.
66 | ASPIRATION HOB
7 8 9 10
5 2
11 12 15
1 3
11. Timer display
12. Minus/Plus timer keys
13. Fan automatic functon display
14. Fan slider control - sensor field
15. Fan automatic mode display
16. Carbon filter state indication (only in
recirculation mode)
17. Grease filter state indication
18. Fan power level display
19. Fan timer display
20. Fan slider display
16 17 18 19
13 14
20
