10- Fixed gear / Starres Fahrwerk
Bottom view /Ansicht von unten
2x6mm screw
CA
..........4
4mm collar
...2
....2
Bottom view /Ansicht von unten
11- Engine mount / Motoreinbau
! Align the mark on both mounts
5/32x1"
Blind-nut
with the mark on the fuselage
4x25mm screw
.................4
...4
!
! Align the mark on both mounts
with the mark on the fuselage
!
! Engine thrust on balk head
is already adjust at factory
4.5mm
Sturz und Zug beachten!
FRONT-VIEW
Vorderansicht
