OPTIONAL ACCESSORIES / BENOTIGTES ZUBEHOR
Minimum 5 channel radio
for airplane with 5 servos
.Motor control x1 .Aileron x2
.Elevator x1 .Rudder x1
GLUE
(Purchase separately)
SILICON
Silicon sealer
TOLLS REQUIRED
Hobby knife
Needle nose Pliers
Sander
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
Masking tape - Straight Edged Ruler - Pen or pencil - Rubbing alcohol - Drill and Assorted Drill Bits
If exposed to direct sunlight and/or heat, wrinkels can appear. Storing the
model in a cool place will let the wrinkles disappear. Otherwise, remove
wrinkles in covering film with a hair dryer, starting with
low temperature. You can fix the corners by using a hot iron.
Bei Sonneneinstrahlung und/oder Wärme kann die Folie erschlaffen bzw. Falten
entstehen. Verwenden Sie ein Warumluftgebläse (Haartrockner) um evtl. Falten aus der Folie
zu bekommen. Die Kanten können Sie mit einem Bügeleisen behandeln. Nicht zuviel Hitze anwenden !
Drill holes using the stated
size of drill
1.5mm
(in this case 1.5 mm Ø)
A B
Use epoxy glue
CONVERSION TABLE
3.0mm = 1/8"
1.0mm = 3/64"
4.0mm = 5/32"
1.5mm = 1/16"
5.0mm = 13/64"
2.0mm = 5/64"
6.0mm = 15/64"
2.5mm = 3/32"
10.5x6 for .40 - 2 cycle engine
11x6 for .46
12x6 for .60
12x7 for .70
13x6 for Brushless Motor
.46 ~ .50 - 2 cycle
Silicone tube
Cyanoacrylate
Glue
Klebstoff
(Purchase separately)
Phillip screw driver
Scissors
!
Take particular care here
Apply cyano glue
CA
10mm = 13/32"
12mm = 15/32"
15mm = 19/32"
20mm = 51/64"
- 2 cycle engine
- 4 cycle engine
- 4 cycle engine
.60 ~.70 - 4 cycle
Li-Po Battery
EPOXY A
CA
EPOXY B
Hatched-in areas:
remove covering
film carefully
Assemble left and right
L/R
sides the same way.
25mm = 1"
30mm = 1-3/16"
45mm = 1-51/64"
Extension for aileron
servo, retract servo.
ESC-60A
Retract landing
gear VQAR04
700 Watt
Brushless Motor
Linkage Stopper x2
(for retract servo)
Epoxy Glue (5 minute type)
Epoxy-Klebstoff (5min-Typ)
Epoxy Glue (30 minute type)
Epoxy-Klebstoff (30min-Typ)
Hex Wrench
Awl
Wire Cutters
Check during assembly that these
parts move freely, without binding
Not included.
X
These parts must be
purchased separately
Retract servo
x1
Low setting
