22- Linkages / Alenkungen
23- Battery / Akku
24- Control Surface / Ruderausschlage
RUDDER STROKE
Seitenruderausschlag
IMPORTANT: Flying your model at these throws will provide you with the greatest chance for successful first flights. If,
after you have become accustomed to the way the Zero flies, you would like to change the throws to suit your taste
, that is fine. However, too much control throw could make the model difficult to control, so remember, "more is not
always better".
BOTTOM VIEW
Elevator rod
Rudder rod
To rudder servo
!
Securely install the battery, ensuring it will not come loose
or rattle during flights.
AILERON STROKE
Querruderausschlag
51/64 ~ 1"
20~25mm
51/64 ~ 1"
20~25mm
Unteransicht
Elevator rod
Connector
To elevator servo
FRONT-VIEW
Vorderansicht
ELEVATOR STROKE
Hohenruderausschlag
15/64 ~ 5/16"
6~8mm
15/64 ~ 5/16"
6~8mm
13/32 ~ 15/32"
10~12mm
13/32"
10mm
