25- Balance / Schwerpunkt
107 mm
4-13/64"
How to add noseweight
To get the correct C.G., Several strips of lead
weight were required in the nose of this model .
To minimize the amount of weight required, it is
desirable to position the weight as far forward
as possible. This can be done by making a
platform form leftover basswood stick and 3.2mm
(1/8") ply wood. Using 4x35mm bolts to mount the
engine would also be long enough to mount the
flatform. The lead should be permanently glued on
with epoxy.
IMPORTANT: Recheck the C.G. After the weight
has been installed.
26- Decor / Aufkleber
Note: Cut out the stickers and apply them in the proper area. Do not peel the backing paper off all at once.
Peel off one corner of the backing and cut off with scissors. Arrange sticker on model and when satisfied adhere the corner without
backing.
Carefully peel back the rest of the backing while at the same time adhering the rest of the sticker.
Try not to make air bubbles, if there are some, carefully puncture sticker (center of bubble) but not model surface with the tip of the
knife or sharp pin and squeeze out the air. At curves stretch sticker and apply a little heat so that no ceases occur. Cut off the excess
that is produced.
IMPORTANT: Please do not clean your model with pure alcohol, only use liquid soap with water or use glass cleaner
to clean on surface of your model to keep the colour not fade.
All details are subject to change
without notice !
DO NOT try to fly an out-of-balance model !
Wing center section
Battery pack
Technische Anderungen und Irrtumer
vorbehalten !
Basswood stick
E-141
VQAO14 Gray
VQAO151 White
450
VQAO15 Green
Flatform
(3.2mm ply)
Lead should be
permanently glued
on flatform with
epoxy
