7- Electric retract landing gear / Einziehfahrwerk
RETRACTED POSITION
ON
GEAR
RECEIVER
OFF
8- Fixed gear / Starres Fahrwerk
3x12mm screw
..........8
3x20mm screw
......16
Nylon gear strap
.......4
3x12mm
screw
Gear mount x 2
Ply gear mount
plate x 2
Square plastic x 2
9- Fixed gear / Starres Fahrwerk
CA
ABS Wheel well cover
EXTENDED POSITION
ELECTRIC RETRACT
LANDING GEAR
Main landing gear
Gear mount
2mm
Wing - bottom view
ELECTRIC RETRACT
LANDING GEAR
Bottom view /Ansicht von unten
Nylon gear
strap
1
3x20mm screw
2mm
Bottom view /Ansicht von unten
3x20mm
2mm
2mm
2
3x20mm
4
2mm
Ply gear
mount flat
Square
plastic
3
