3. Commissioning, use

The expansion module, in position on the fastened control unit cover, that allows the power supply and control unit to be switched
"On" in place, menu [11-3-8] gives access to the version view of the following extension:
Service menu [11] »
If the version number under [11-3-8] is missing, the module is not ready for operation (see page 6 - Internal and external error
messages). The initialized module (ready for operation) enables the signal output from Start in the start menu [9-9] (equipment
operational). Changes to the configuration that stop the control functions (in the menu navigation, confirming the question 'Stop
system?') interrupt the Capacity signal output, pressure analogue.
To maintain the signal output, it is essential that the power supply is available, the control unit is switched "On" and the equipment
sensors are functioning properly. To service the sensors, the requisite factory settings/initial conditions must be restored.
Note: Drawings of components may differ from actual parts supplied.
Commissioning, use
Location of data in menu:
information
Internal messages; LED displays on the extension (nos. 1.3 and 1.4);
Status
Green "Off"
Green "On"
Green "flashing"
Red "Off"
Red "On"
Red "intermittent"
External message; applicable error message after going to message display on terminal if error message shown:
Display
60
Extension
6
» Version information [11-3] »
[11]
Menu Menu
Data transfer Date, time
Main menu
Order Equipment
number information
Service
menu
Controller Terminal
Version
Description
Extension not recognised, not available, no
access (version number under [11-3-8] not
available).
Extension recognised.
Data transfer
No errors.
Use of module blocked
(Exceeded Licensing).
Last action resulted in error.
Description
Last external extension action resulted in error
(identical to LED red, flashing intermittently;
no. 1.4).
Important: Error not saved, not contained in menu
[11-6]
(Error history, analysis).
» slot 3 [08.03.11] »
[11-3]
Menu Menu Configuration
Language Log-in menu
Version Commis
information sioning Maintenance
Forward Loader Language
[11-3-8]
Start-up Operation
menu menu Service menu
Hours of Top-up/
Error list operation draining
Slot 1 Slot 2 Slot 3
measures
Control unit, power supply;
use indicated slot; clean contact surfaces of the
connector strip.
Function available.
-
-
Use extension on one of three previously used
control units.
Carry out positioning under initial conditions (see
also: "External error message",
60 Extension).
measures
Acknowledgement deactivates the error message
and the flashing red LED. (No consequences if
the error is not acknowledged). Check extension
positioning (extension may be removed).
Network
menu
Slot 4
