SolarEdge SE3K Handbuch Seite 14

9
Connecting AC and Protective Earth (PE)
The inverter can either support 4 wire + PE or 3 wire + PE connection
Overcurrent protection for the AC output must be provided by others, see manual for guidance
PE Wire
15 N*m
Max 70 mm
2
10 -11 mm
12 MAN-01-00784-1.3
5
4
6
1
Brown
Black
Connect PE
OR
wire first
12 N*m
Yellow/Green
Optional PE wire
30 - 50 mm
When using a stranded wire, use of
ferrule is at the installer discretion
3
2
21 N*m
Gray
Blue
9 N*m
AC
Yellow/Green
Max width 33 mm
Ø 10 mm
CAUTION!
• For aluminum wires, USE
ONLY aluminum lugs
• For copper wires, USE ONLY
copper tin-plated lugs
One-hole, standard barrel,
compression lugs only, 600V
Chassis Ground
Max
thickness
7 mm
Heat shrink
insulation
Max: 120 mm 2
