Gb Reversing The Door M150/180 - Danfoss M150 Servicehandbuch

GB
Reversing the door M150/180
If reversing the door with the unit in normal position, then it is recommended to be two people.
Else the unit can be placed on its back on the floor. If this method is used the unit must be
placed in normal upright position at least two hours before connecting to power.
Extension cords terminal block and left bracket is optional
(M190 see page 18)
.
Request a spare parts list
1. M150 / M180
Disconnect the power supply
Loosen the two screws in the top panel.
Pull out carefully the top panel.
1. M190
See page 18
2. Unscrew the two screws in the lower panel.
3. Remove the cover by using suitable tool
and a hammer
12
