General system information on Homematic

4 General system information on
Homematic
This device is a part of the Homematic home control
system and works with the bidirectional Homematic
wireless protocol. All devices are delivered in a stan-
dard configuration. The functionality of the device can
also be configured with a programming device and
software. Further resulting functionality and the ad-
ditional functions provided in the Homematic system
combined with other components are described in the
Homematic WebUI Manual. All current technical docu-
ments and updates are provided under
www.homematic.com.
5

Installation

The actuator for ceiling void mount installations is sui-
table for invisible mounting in suspended ceilings for
example. Fastening tabs are provided on the device to
make fastening comfortable with screws.
The installation of the described actuator is shown in
the following connection diagrams. Remove the cover
over the terminal strip for making connections to the
device. Connect the actuator to L and N for the sup-
ply. Run the switched/dimmed channel circuit to the
consumer.
