BOX SIZES

Box, square, 45°, roll-formed
SEAT BELT CONTROL
box type Dimension A
125
137
150
165
180
205
ENGINE CONTROL
box type Dimension A
125
137
150
165
180
205
13
DimensionB
126 mm 126 mm
140 mm 140 mm
151 mm 151 mm
168 mm 168 mm
183 mm 183 mm
208 mm 208 mm
DimensionB
126 mm 126 mm
140 mm 140 mm
151 mm 151 mm
168 mm 168 mm
183 mm 183 mm
208 mm 208 mm
Total height of the roller shutter including box
37
PVC-Profil Mini PK
until 1.440 mm
until 1.890 mm
until 2.230 mm
until 2.610 mm
until 3.100 mm
until 4.550 mm
Total height of the roller shutter including box
PVC-Profil Mini PK 37
-
until 1.780 mm
until 2.160 mm
until 2.390 mm
until 3.060 mm
until 4.110 mm
B
A
39
ALU-Profil Mini PA
until 1.240 mm
until 1.560 mm
until 1.960 mm
until 2.390 mm
until 2.950 mm
until 4.320 mm
ALU-Profil Mini PA 39
-
until 1.440 mm
until 1.800 mm
until 2.280 mm
until 2.790 mm
until 4.050 mm
