MIX 10 NG2 – RS 232 Interface
S
ent Commands
The following commands are sent from the MIX 10 NG2:
Cmd Data0 Data1
C1 00~04
C2 00~4F 00~04
C3 00~4F 10~15
C4 00~4F 00~04
C5 00~4F 10~15
2 0 Bit 0
C8
2 1 Bit 1
C9 00~01 10~15
CA 00~01 01~02
CB 00~03 00~01
CE 00~01 00~04,10~15
D0 00~7F
D1 00~7F
D2 00~7F
D3 00~4F
D4 00~7F
D7 00~03
D8
"10" ~ "15" represent the channels MIC1~MIC6.
"00" ~ "04" represent the channels LINE, SUB-L, SUB-R, MASTER-L,MASTER-R.
An acknowledged message is directly sent from the MIX 10 NG2 after having received a request.
Example:
Selection of the CD line input
PC –> Device
DLE STX
10 02
01.02.2008 10:30 Uhr Seite 30
Command
Line source selected
Stereo volume currently adjusted
value "N"
Mic volume currently adjusted value
"N"
Stereo volume now value "N"
Mic volume now value "N"
Auto ducking
Ducking manually
Mic ducking
Stereo ganged
Load or save preset
Mute flag
Fade-out speed
Fade-in speed
Ducking threshold value
Ducking reduction
Ducking hold
Switch-on status
Programmed version (V 1.0)
Device No. Len Cmd
01 02 A1
Data0 Data1
line 1 - 4 or none(0)
N - value stereo no
N - value mic no
N - value stereo no
N - value mic no
1 = on , 0 = off
1 = on , 0 = off
01 = enabled ,
mic no
00= disabled
01 = enabled , 01 = sub group,
00= disabled 02 = master
0-default / preset 1,2,3 00 = load , 01 = save
1 = on , 0 = off stereo / mic
N - value
N - value
N - value
N - value
N - value
preset 1/2/3/switch-off
status(0)
Data DLE ETX
03 10 03
30
Check Sum
A0
